BOSCH PERFORMANCE CX MOTOR

TECHNICAL SPECIFICATIONS

BOSCH PERFORMANCE CX MOTOR

Efficient energy use

Optimal motor and transmission performance for tackling long, steep climbs.

Always at maximum power

Ideal for fast intermediate sprints and quick changes of pace.

Reduced noise level

For quiet riding with high motor power at all pedaling frequencies.

Motor torque 85 Nm

For powerful acceleration in a compact format.

Assistance up to 340%

For powerful thrust, extremely sporty riding and fast sprints.

Maximum speed 25 km/h

Constant assistance up to 25 km/h, even on long uphill stretches.

BOSCH KIOX 300 DISPLAY

Exciting features

Robust and intelligent display for sporty tours, monitoring fitness data, and optimizing your training. Regular OTA updates keep the Kiox 300 always up to date with new features via the eBike Flow app.

Easy to read, stylish design

Compact but powerful. Color display that is easy to read both during the day and at night. Simple operation via LED Remote, with visual support via animations and images. Resistant to splashes and dust.

Useful support

Activate Walk Assist via LED Remote for valuable assistance when climbing. Clear displays for intuitive operation and information on remaining range for each riding mode.

Customized positioning

Adjustable mount for optimal viewing at all times during your ride.

eBike Flow app – Make your eBike experience your own!

Download updates and new features via Bluetooth.

• Automatically record your routes and sync with Apple Health
• Customize your riding modes (Eco, Tour, Sport, Turbo)
• Monitor battery status, range, distance, and maintenance

FRAME

Frame: C:62® Monocoque Advanced Twin Mold Technology, 6061 T6 aluminum rear triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, integrated battery, advanced internal cabling

Sizes: Size Split: 27.5: S (16“) / 29: M (18”), L (20“), XL (22”)

Fork: RockShox 35 Silver TK Air, Tapered, 15x110mm, eMTB Approved, 150mm, with Lockout

Shock: RockShox Deluxe Select+, 205x60mm (27.5: 185x55mm), Rebound Adjustment, Trunnion Mount, Lockout

Headset: ACROS AZF-1035, ICR, BlockLock 120°, ZS 56mm

EQUIPMENT

Handlebar stem: CUBE Performance Stem E-MTB, 31.8mm

Handlebar: Newmen Evolution SL 318.25, 760mm

Grips: ACID React Pro

Saddle: Natural Fit Venec

Seatpost: CUBE Dropper Post with handlebar control, internal routing, Ø31.6mm

Seat clamp: CUBE Screwlock Semi Integrated, 34.9mm

DRIVETRAIN

Rear derailleur: Shimano XT RD-M8100-SGS ShadowPlus, 12-speed

Shifter: Shimano Deore SL-M6100, Rapidfire-Plus

Chain guide: Reverse Flip-Guide E-Chain Guide, Direct Mount, GEN4

Crankset: ACID E-Crank 165mm (27.5: 36T / 29: 34T)

Cassette: Shimano Deore CS-M6100, 10-51T

Chain: Shimano CN-M6100

E-BIKE SYSTEM

Motor: Bosch Performance CX Gen 4 (85Nm), 250W, Smart System

Battery: Bosch PowerTube 750Wh

Charger: Bosch 4A

Control: Bosch LED Remote

Display: Bosch Kiox 300

WHEELS

Rims: CUBE EX30, 32 holes, Disc, Tubeless Ready

Front hub: Shimano HB-MT400-B, 15mm, Boost, Centerlock

Rear hub: Shimano FH-MT410-B, 12mm, Boost, Centerlock

Tires: Schwalbe Nobby Nic Performance Line, 2.6”

BRAKES

Brakes: Sram DB8, hydraulic disc brake (203/203mm)

ADDITIONAL INFORMATION

Weight: 24.8 kg

Wheel sizes:

• 16“ = 27.5”
• 18“, 20”, 22“ = 29”Bike type: Full-suspension E-MTBUser: UnisexFrame material: CarbonModel year: 2023Battery capacity: 750WhDisplay: Bosch Kiox 300
